The MAX9590ETU+ is a Programmable Gamma Reference Buffer. It provides 14 programmable voltage references and 4 static voltage references for gammacorrection in TFT-LCD displays. The 14 programmable reference voltages are dividedevenly into seven upper and seven lower voltages for theupper and lower gamma curves of LCD column drivers. The MAX9590ETU+ is available in a 38-pin TQFN packageand is specified for operation over the -40℃ to +85℃ temperature range. Applications include TFT-LCD Displays and Industrial Reference Voltage Generators.
Parametrics
MAX9590ETU+ Ordering Information: (1)temperature range: -40℃ to +85℃; (2)pin package: 38 TQFN(5mm x 7mm).
Features
MAX9590ETU+ features: (1)14 Programmable Reference Voltages; (2)4 Static Reference Voltages; (3)Independent DACs with 8-Bit Resolution; (4)Two Register Banks for Two Sets of Gamma Values; (5)Fast Switching between Gamma Values 16.5V (max) Operating Voltage; (6)Output Swing within 150mV of Rails; (7)Peak Current Greater than 200mA; (8)Output Channels Tri-Stated During Wake-Up.
