Product Summary

The AD9624AR is one of a family of very high speed and widebandwidth amplifiers utilizing a voltage feedback architecture.These amplifiers define a new level of performance for voltagefeedback amplifiers, especially in the categories of large signalbandwidth, slew rate, settling, and low noise.

Parametrics

AD9624AR specifications: (1)Minimum Stable Gain: 6V/V; (2)Harmonic Distortion (20 MHz): 66dB; (3)Large Signal Bandwidth (4 V p-p): 200MHz; (4)SSBW (0.5 V p-p): 300MHz; (5)Slew Rate: 2200V/μs; (6)Rise/Fall Time (0.5 V Step): 1.5ns; (7)Settling Time (to 0.1%/0.01%): 8/14ns; (8)Input Noise (0.1 MHz–200 MHz): 32μVrms.

Features

AD9624AR features: (1)350 MHz Small Signal Bandwidth; (2)130 MHz Large Signal BW (4 V p-p); (3)High Slew Rate: 1200 V/ s; (4)Fast Settling: 11 ns to 0.01%/7 ns to 0.1% 3 V Supply Operation.

Diagrams

AD9624AR CONNECTION DIAGRAM
