PA28F400BV-T120

4-MBIT (256K X 16, 512K X 8), smartvoltage boot block flash memory, SOP44

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.40~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $2.40~3.00

PartNumber:: PA28F400BV-T120

Brand:: Intel Corporation - Intel | Pack: SOP | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Saintly's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-03

From Other Seller

Part Number:PA28F400BV-T120
US $2.40 - 3.00
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
ECA1HHG220

US $2.00 - 10.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The PA28F400BV-T120 is a high-performance, 4-Mbit (4,194,304 bit) flash memory organized as either 256 Kwords of 16 bits each (28F400 only) or 512 Kbytes of 8 bits each (28F400 and 28F004B). The PA28F400BV-T120 is also designed with an Automatic Power Savings (APS) feature which minimizes system battery current drain, allowing for very low power designs.

Parametrics

PA28F400BV-T120 absolute maximum ratings: (1)Commercial Operating Temperature: During Read:0℃ to +70℃, During Block Erase and Word/Byte Program: 0℃ to +70℃, Temperature Bias:–10℃ to +80℃; (2)Extended Operating Temperature: During Read: –40℃ to +85℃, During Block Erase and Word/Byte Program: –40℃ to +85℃, Temperature Under Bias: –40℃ to +85℃; (3)Storage Temperature: –65℃ to +125℃; (4)Voltage on Any Pin(except VCC, VPP, A9 and RP#) with Respect to GND: –20V to +70V; (5)Voltage on Pin RP# or Pin A9 with Respect to GND: –20V to +135V; (6)VPP Program Voltage with Respect to GND during Block Erase and Word/Byte Program: –20V to +140V; (7)VCC Supply Voltage with Respect to GND: –20V to +70V; (8)Output Short Circuit Current: 100 mA.

Features

PA28F400BV-T120 features: (1)Low Power Consumption: Max 60 mA Read Current at 5V, Max 30 mA Read Current at 2.7V-0.6V; (2)x8/x16-Selectable Input/Output Bus: 28F400 for High Performance 16- or 32-bit CPUs; (3)x8-Only Input/Output Architecture:28F004B for Space-Constrained 8-bit Applications; (4)Optimized Array Blocking Architecture; (5)One 16-KB Protected Boot Block; (6)Two 8-KB Parameter Blocks; (7)One 96-KB Main Block; (8)Three 128-KB Main Blocks; (9)Top or Bottom Boot Locations; (10)Absolute Hardware-Protection for Boot Block; (11)Software EEPROM Emulation.
