ADG508ATQ

CMOS, 4-/8-Channel, monolithic analog multiplexer, 16-lead DIP/SOIC, 20-lead PLCC/LCC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.30~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $2.30~2.50

PartNumber:: ADG508ATQ

Brand:: Analog Devices - ADI | Pack: DIP | D/C: 94+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Saintly's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-04-12

From Other Seller

Part Number:ADG508ATQ
US $2.30 - 2.50
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
YL-G709

US $65.00 - 68.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The ADG508ATQ is a CMOS monolithic analog multiplexer with eight channels and dual four channels, respec-tively. TheADG508ATQ switches one of eight inputs to a common output, depending on the state of three binary addresses and an enable input. It is designed on an enhanced LC2MOS process that gives an increased signal capability of VSS to VDD and enables operation over a wide range of supply voltages. The device can comfortably operate anywhere in the 10.8 V to 16.5 V single- or dual-supply range.

Parametrics

Absolute maximum ratings: (1)VDD to VSS: 44 V; (2)VDD to GND: 32 V; (3)VSS to GND: –32 V; (4)Analog Inputs1, Voltage at S, D: VSS - 2 V to VDD + 2 V or 20 mA, whichever occurs first; (5)Continuous Current, S or D: 20 mA; (6)Pulsed Current S or D, 1 ms Duration, 10% Duty Cycle: 40 mA; (7)Digital Inputs, Voltage at A, EN: VSS - 4 V to VDD + 4 V or 20 mA, whichever occurs first; (8)Power Dissipation (Any Package) Up to 75℃: 470 mW; (9)Derates Above 75℃ by: 6 mW/℃; (10)Operating Temperature: Commercial (K Version): -40℃ to +85℃; Industrial (B Version): -40℃ to +85℃; Extended (T Version): -55℃ to +125℃; (11)Storage Temperature Range: -65℃ to +150℃.

Features

Features: (1)44 V supply maximum rating; (2)VSS to VDD analog signal range; (3)Single-/dual-supply specifications; (4)Wide supply range: 10.8 V to 16.5 V; (5)Extended plastic temperature range: -40°C to +85°C; (6)Low power dissipation: 28 mW maximum; (7)Low leakage: 20 pA typical; (8)Available in 16-lead DIP/SOIC and 20-lead PLCC/LCC packages; (9)Superior alternative toDG508A, HI-508.
