Product Summary
The AD7506JN is a monolithic CMOS 16-channel analog multiplexer packaged in a 28-pin DIP or a 28-terminal surface mount package.
Parametrics
AD7506JN absolute maximum ratings: (1)VDD-GND:+17V; (2)VSS-GND:-17V; (3)V between any switch terminals:25V; (4)digital input voltage range:VDD to GND; (5)switch current:20mA; (6)storage temperature:-65℃ to +150℃; (7)lead temperature(soldering, 10sec):+300℃.
Features
AD7506JN features: (1)RON:300Ω; (2)power dissipation:1.5mW; (3)TTL/DTL/CMOS direct interface; (4)break-before-make switching.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 AD7506JN |
|
IC MULTIPLEXER 16X1 28DIP |
Data Sheet |
Negotiable |
|
||||||||||||||||
|
AD7506JNZ |
|
IC MULTIPLEXER 16X1 28DIP |
Data Sheet |
|
|
||||||||||||||||
