Product Summary
The CY2907SC-105 is a general purpose clock generator designedfor use in a wide variety of applications—from graphics to PCperipherals to disk drives. The CY2907SC-105 generates selectable system clockfrequencies from a single reference input (crystal or referenceclock). The CY2907SC-105 is configured with an EPROM array,similar to the other devices in the Cypress EPROM Programmable Clock family, making it easy to customize for any application. Furthermore, the CY2907SC-105 is compatible with all industry-standard 9107 and 9108 clock synthesizers.
Parametrics
CY2907SC-105 absolute maximum ratings: (1)Supply Voltage: –0.5 to +7.0V; (2)Input Voltage: –0.5V to VDD+0.5V; (3)Storage Temperature (Non-Condensing): –65℃ to +150℃; (4)Max. Soldering Temperature (10 sec): +260℃; (5)Junction Temperature: +150℃; (6)Static Discharge Voltage: >2000V.
Features
CY2907SC-105 features: (1)Single phase locked loop (PLL) architecture; (2)EPROM programmability; (3)Factory-programmable (CY2907, CY2907I) orfield-programmable (CY2907F, CY2907FI) device options; (4)Up to two configurable outputs; (5)Low skew, low jitter, high accuracy outputs; (6)Power management (power down, OE); (7)Frequency select option; (8)Configurable 5V or 3.3V operation; (9)8-pin or 14-pin SOIC packages.
Diagrams
 |
