AD7576KN

10 us, 8-Bit ADC, 18-pin DIP, 7V, AD7576KN, Analog Devices

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.30~4.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $3.30~4.00

PartNumber:: AD7576KN

Brand:: Analog Devices - ADI | Pack: DIP | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Saintly's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-04

From Other Seller

Part Number:AD7576KN
US $3.30 - 4.00
iphone5 data cable

US $4.00 - 5.00 / Piece
(0) Remove
AT25256AW-10SU-2.7

US $0.65 - 1.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AD7576KN is a low cost, low power, microprocessor compatible 8-bit analog-to-digital converter, which uses the successive approximation technique to achieve a fast conversion time of 10μs. The AD7576KN is designed to operate with an external reference of +1.23V and converts input signals from 0V to 2VREF. The AD7576KN is designed for single +5V operation, has on-board comparator, interface logic, and internal/external clock option. The AD7576KN is fabricated in an advanced, all ion-implanted high speed linear compatible CMOS process and is packaged in a small, 0.3" wide, 18-pin DIP.

Parametrics

AD7576KN absolute maximum ratings: (1)VDD to AGND: -0.3V, +7V; (2)VDD to DGND:-0.3V, +7V; (3)AGND to DGND:-0.3V, VDD; (4)Digital input voltage to DGND(pins 1-3):-0.3V, VDD; (5)Digital input voltage to DGND(pins 4, 6-8, 10-14):-0.3V, VDD; (6)CLK input voltage to DGND:-0.3V, VDD; (7)VREF to AGND:-0.3V, VDD; (8)AIN to AGND:-0.3V, VDD; (9)Operating temperature range:0℃ to 70℃; (10)storage temperature range:-65℃ to +150℃; (11)lead temperature(soldering, 10sec):300℃; (12)power dissipation to +75℃:450mW; (13)derates above 75℃ by:6mW/℃.

Features

AD7576KN features: (1)single +5V operation with external positive reference; (2)fast conversion time:10μs; (3)no missed codes over full temperature range; (4)microprocessor compatible; (5)low cost; (6)low power(15mW); (7)100ns data access time.
